Application:
JINLONG double Jacket steel tape Armored cables are designed for direct burial installation with lashing method. The loose tube design with a metallic strength member and dluble jacket for provides stable performance over a wide temperature range and is compatible with any telecommunication grade optical fiber.
Design & Construction：
* S-Z stranded (up to 288 fibers)
*G652D optical fiber
*non-metallic armored
*Steel wire for center strength member
*Low attenuation, low dispersion, stable control of excess length makes the optical cable perfect mechanical and environmental properties.
*With simple structure easy to install
*PE double sheath materials
*Designed in accordance with applicable industry technical specifications, standards and references including IEC and EN
Mechanical and Environmental Test.
IEC 60794-1-E1：Tensile Strength
IEC 60794-1-E3 ：Crush Test
IEC 60794-1-E4：Impact Test
IEC 60794-1-E6：Repeated Bending
IEC 60794-1-E7：Torsion
IEC 60794-1-F5B：Water Penetration
IEC 60794-1-F1：Temperature Cycling
IEC 60794-1-E14：Compound Flow
Typical Parameters
| Fiber count | Cable outer dia(mm) | Cable weight(kg/km) | Min.bending radius(mm) | Permissible tensile force(N) | Permissible pressure force(N/100mm) |
| Static | Dynamic | Short-term | Long-term | Short-term | Long-term |
| 2-36 | 12.4 | 143 | 12.5D | 25D | 3000 | 1000 | 3000 | 1000 |
| 38-72 | 13 | 163 | 12.5D | 25D | 3000 | 1000 | 3000 | 1000 |
| 74-84 | 13.7 | 180 | 12.5D | 25D | 3000 | 1000 | 3000 | 1000 |
| 86-96 | 14.3 | 195 | 12.5D | 25D | 3000 | 1000 | 3000 | 1000 |
| 98-108 | 15 | 213 | 12.5D | 25D | 3000 | 1000 | 3000 | 1000 |
| 132-144 | 17 | 268 | 12.5D | 25D | 3000 | 1000 | 3000 | 1000 |
| 288 | 20.2 | 370 | 12.5D | 25D | 3000 | 1000 | 3000 | 1000 |
"D" is cable diameter. |
All sizes and proformance values can be specified by customer
